Slot Drains
Our stainless steel trench drains are designed for easy clean up in wash-down enviroments. All drains meet ANSI, ASTM, ADA, ASME Standard A112.6.3 and A112.3.1.Standard construction has a load rating of 10,000 lbs (assuming adequate foundation). Grating is not required, thus removing maintenance and trip hazard.
Material
304 Stainless Steel
316 Stainless Steel
316 Stainless Steel
Cover
Drilled
Standard
Standard
Finish
Polished Basket
Polished Drain ID
Polished Top Plate & Cover
Standard Industrial (Standard)
Polished Drain ID
Polished Top Plate & Cover
Standard Industrial (Standard)
Outlet Size
2 Inch
3 Inch
4 Inch
6 Inch
3 Inch
4 Inch
6 Inch
Outlet Tyle
Custom
Exterenal Thread
Internal Thread
No Hub
Exterenal Thread
Internal Thread
No Hub
Options
Cross Collector Type-C
Mounting Ring
Premier Fitting 1/2″ from Top
Premier Fitting 3/8″ from Top
P-Trap
Mounting Ring
Premier Fitting 1/2″ from Top
Premier Fitting 3/8″ from Top
P-Trap
Slope
1/8 in. per ft.
1/4 in. per ft.
1/4 in. per ft.
Trough Bottom Type
“U” Shaped (Standard)
“V” Shaped
Flat
“V” Shaped
Flat
Anchors
No, Not Necessary
Yes, On Existing Floors
Yes, On New Floors
Yes, On Existing Floors
Yes, On New Floors
Outlet Schedule
Custom
SCH 10
SCH 40 (Standard)
SCH 10
SCH 40 (Standard)
Drain Configuration
Cross Collector Type-C
End Collector Type-E
Tee Collector Type-T
End Collector Type-E
Tee Collector Type-T
